Produtos > Vaccines Line > BT 1100/700

BT 1100/700

700 liters

BT 1100/700

Smart Refrigerator to storage of vaccines, drugs and medicines with temperature from 2°C to 8°C, alarms, dialer and temperature homogenization system.

700 liters
2°C to 8°C
197H X 78W X 98D (cm) external
130H X 65W X 85D (cm) internal
6 sliding drawers
Triple glass door
Emergency System for 24 hours

LIGHTING

Led lamps with automatic activation when opening the door and/or optional programmable timer with external access even when the door is closed.



TEMPERATURE HOMOGENIZER

The forced-air circulation ensure perfect homogenization of the temperature at all points inside the equipment. It shuts down when the door is opened.



THERMAL INSULATION

High density injected polyurethane.



DOOR

Triple glass vertical door with anti-fog system, magnetic profile seal with opening alarm.



REFRIGERATION

Through airtight compressor with CFC-free R-134 A ecological gas circulation, forced-air evaporator unit, automatic defrost system with condensate evaporation.



CONTROL PANEL

On the top of the equipment with main switch and protection fuses on the back and membrane-type front panel with soft-touch keys. Electronic microprocessed thermostat with temperature and programming parameters decimal digital display, locking system against inadvertent handling, system that re-establishes the programmed parameters even with abrupt energy variation or equipment shutdown. Filter against electromagnetic noise. Automatic function check system. Equipped with ITTC type sensors. 2.3 amperes battery to support the functions of the electronic panel, to trigger alarms and the dialer on equipment without emergency system.



VISUAL SIGNS

Visual and simultaneous display for commercial power, temperature deviations, open door, power failure and battery charge level. Electronic recorder of maximum and minimum temperatures reached.



AUDIOVISUAL ALARMS

Temperature below 2°C, temperature above 8°C (or 6°C for storage of blood and its components), or adjustable by user. Alarms for electric power cut, open door, inhibit key to silence the buzzer for 15 minutes, or adjustable by user. Equipped with alarm simulator.



WORKING RANGE

Minimum of 2°C and maximum of 8°C (or 6°C for storage of blood and its components), with set point at 4°C, or adjustable by user, with a variation of + -0.1°C.



TEMPERATURE RECORDER

Electronic recorder of maximum and minimum temperatures reached.



SECURITY SYSTEM

Thermostat installed in parallel with the electronic controller of the equipment, automatically taking control of compressor functions whenever the electronic control fails.



DIALER

Automatic system that makes telephone calls via telephone switchboard or direct fixed line for up to six numbers whenever the equipment alarms at critical temperature.



MANAGEMENT SOFTWARE

Real time follow-up, access to charts and reports remotely via mobile application, including retroactive data, allowing management of the refrigerator via Internet with RS232/485/DB-25 serial output.



OPERATION

Bivolt 127/220 VOLTS 50/60 Hz



WARRANTY

1 year.



ATTENTION

Panel and display configurations may vary depending on equipment features. Merely illustrative images. Equipment design may change without notice.



Consult different autonomy options with our commercial consultants.

Temperature controller certification for proof of measurement uncertainty (IM, errors, trends, etc.), together with INMETRO (RBC) proven traceability.
With the logo of the establishment and the image to be chosen by the customer. See custom sticker options by clicking here.
Automatic system that makes telephone calls via telephone exchange or direct fixed line, for up to six numbers (cellular or landline) if the equipment alarms by critical temperature.
Cylindrical lock system for locking the door.
Through 12 volt (dc) converter to 110/220 volts (ac), maintaining all electro-electronic functions, including the free range¹ cold compressor according to the model from 2 to 72 hours. Integrated into the cabinet, mounted on the bottom of the chamber, with sealed battery drawer. AutonomiaEmergency of the Emergency System may vary due to ambient temperature and battery usage time.
System for extracting temperature data via flash drive / data logger.
Ethernet communication data converter (internet or intranet). Interface that allows Biotecno cameras to connect to networked computers. Through the IP address of the converter it is possible to access and manage the equipment in local network through the Internet.
